Overview
Analysis Method: Vacuum static method
Measuring range: SSA Lower to 0.1M2 / g, not known upper limit
Pressure Measurement
-Range : 0-120 KPa
-Precision : ±0.1% FS
Liquid nitrogen container
-Volume : 1.5 L
-Quantity: 1
-Hold time : 10 hrs
Sample Tube
-Material : Glass
- Volume: 2 － 10mL
Vacuum Pump
-Pumping Speed : 30L/min
- Degree of Vacuum : 7X10-2Pa (7X10-4torr)
Computer Requirements
- CPU : 2G Hz
- RAM : 256M
- Hard Disk : 1GB
- Monitor : 1024X768CRT
- Interface : RS232/USB
-Operating System : WIN98/Me/2K/XP
Output Reports : BET Specific Surface Area
Size & Weight: 610mm W x 450mm D x 680mm H , 70 kg/154 lb
Power
-Host : AC220V/115V(optional)  100W
-Vacuum Pump : AC220V/115V(optional)  500W



~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
